Introduction



Valve specification and feature:





The high quality of seat rubber ensures its antaging performance and excellent re-elasticity, well-sealing
  Body Type: Non-rising stem or rising stem
Size: DN50-DN300 (212)
Nominal Pressure: PN10/PN16
Design Standard: BS 5163
Body Flange Drilling: DIN2501;BS4504;GB17241.6
Face to Face: BS5163
Test Inspection: API598; GB13927
Suitable Medium: Water,Sewage, etc.
Operations:Hand Wheel




     Features
1)      Flat bottom full bore design, which avoids odds and ends healed up, ensures there is no effect on the sealing performance dureing long using.
2)      Epoxy painting on the body, which isolated to the medium can avoid effectively corrosion.
3)      Triple sealing to protect against leakage in shaft, which ensures no leakage of valve.
4)      The inverted sealing actuator guarantee that the seal packing can be changed without disassembling the using valve.
5)      The high quality of seat rubber ensures its antaging performance and excellent re-elasticity, well-sealing and no need to maintain.
